hxcpp_JIT

hxcpp_JIT lets you compile and run native C++ code at runtime from Haxe. It wraps Clang's interpreter (Clang-Repl) in a small C library and exposes it with a simple Haxe class.

Define a function in a string or a file, then call it, read variables, or change them, all while your program is running.

Note

Works only on hxcpp and Windows 10 (21H2 or higher) x64 or Windows 11.

Will be updated whenever a new version of LLVM comes out. Since LLVM updates bi-weekly, hxcpp_JIT will be updated bi-weekly as well.

Installation

haxelib install hxcpp_JIT

Enter this command in the command prompt to get the library, then add it to your Haxe project.

Haxe Projects

Add this to build.hxml to add hxcpp_JIT to your Haxe build.

-lib hxcpp_JIT

OpenFL Projects

Add this to project.xml.

<haxelib name="hxcpp_JIT"/>

Requirements

Windows 10 x64 (21H2 or higher) or Windows 11
All Visual C++ Redistributable Runtimes (installed automatically by the setup)
Visual Studio 2019 (For building Haxe only)
- Windows 10 SDK (10.0.19041.0) (For building Haxe only)
- MSVC v142 - VS 2019 C++ x86/64 build tools (Latest) (For building Haxe only)
Visual Studio 2022 (installed automatically by the setup)
- Windows 11 SDK (10.0.22621.0) (Works on Windows 10)
- MSVC v143 - VS 2022 C++ x86/64 build tools (Latest)
- C++ ATL for latest v143 build tools (x86 & x64)
CMake (For building the .DLL only)
Ninja (For building the .DLL only)
LLVM Project 23.1.4 (For building the .DLL only)

Everything except the items labeled "for building Haxe only" or "for building the .DLL only" is required for both building and running. Any Haxe program that uses hxcpp_JIT will not run without these requirements.

You don't have to install the runtime requirements yourself. The items marked "installed automatically" are handled by the setup that is built into every program that uses hxcpp_JIT.

Automatic setup

hxcpp_JIT includes hxcpp_JIT_setup, a small program that checks for the Visual C++ Redistributables, MSVC build tools, Windows SDK and ATL, and installs any that are missing.

The setup exe is embedded in your compiled program, so there is no extra file to copy or ship. When your program starts:

The embedded setup is extracted to %TEMP%\hxcpp_jit\setup_<hash>.exe (once per build, later launches reuse it).
It runs silently to check the machine. If everything is installed, your program continues as normal.
If something is missing, a window opens that tells the user what is missing. The user presses Install, and your program continues once everything is installed.

The extracted copy is left in the temp folder so later launches can reuse it. The setup needs administrator permission and an internet connection to install components, and everything is downloaded from Microsoft.

See the hxcpp_JIT_setup README for its arguments, exit codes and how to build it.

To update the embedded setup, replace build/hxcpp_jit_setup.exe in this project and recompile your Haxe project. It is read at Haxe compile time, so already compiled programs keep the old version.

hxcpp_JIT.dll and hxcpp_JIT.lib are both precompiled and included with the project, so you can skip the .DLL building process entirely. When you compile the Haxe project, hxcpp_JIT.dll will be automatically copied to the build output directory. You still need everything required to run the application.

The precompiled hxcpp_JIT.dll is compressed with upx.

Building the DLL

This part of the README explains how to build the hxcpp_JIT.dll and hxcpp_JIT.lib that hxcpp_JIT actually needs.

Step 1

Download LLVM Project 23.1.4 and extract the source code into a folder called llvm-project in the root directory of the project. Make sure the put the source files in llvm-project/, not the llvm-project-llvmorg-23.1.4 folder in the ZIP.

Step 2

You must configure LLVM before building it. Run x64 Native Tools Command Prompt for VS 2022 as administrator. Run cd path\to\hxcpp_JIT, then switch to PowerShell by typing and entering powershell.

After that, run this command. cmake -S llvm-project/llvm -B llvm-build -G Ninja -DCMAKE_BUILD_TYPE=Release -DCMAKE_C_COMPILER=cl -DCMAKE_CXX_COMPILER=cl -DLLVM_ENABLE_PROJECTS=clang -DLLVM_TARGETS_TO_BUILD=X86 -DLLVM_ENABLE_ASSERTIONS=ON -DLLVM_INCLUDE_TESTS=OFF -DLLVM_INCLUDE_EXAMPLES=OFF -DLLVM_INCLUDE_BENCHMARKS=OFF -DLLVM_INCLUDE_DOCS=OFF -DCLANG_INCLUDE_TESTS=OFF -DCLANG_INCLUDE_DOCS=OFF -DLLVM_ENABLE_ZLIB=OFF -DLLVM_ENABLE_ZSTD=OFF -DLLVM_ENABLE_LIBXML2=OFF -DLLVM_PARALLEL_LINK_JOBS=2

Step 3

To actually build LLVM, run this command.

cmake --build llvm-build --target clangInterpreter clangFrontend clang-resource-headers LLVMOrcJIT LLVMX86CodeGen LLVMX86AsmParser LLVMX86Desc LLVMX86Info

This will take a while.

Step 4

Now, to build hxcpp_JIT.dll and hxcpp_JIT.lib, run this command. $ws = (Get-Location).Path.Replace('\','/')

After that, run this. cmake -S . -B build -G Ninja -DCMAKE_BUILD_TYPE=Release -DCMAKE_C_COMPILER=cl -DCMAKE_CXX_COMPILER=cl "-DLLVM_DIR=$ws/llvm-build/lib/cmake/llvm" "-DClang_DIR=$ws/llvm-build/lib/cmake/clang"

Finally, run this to build hxcpp_JIT.dll and hxcpp_JIT.lib.

cmake --build build

This will create both files in the build/ folder in the root directory. You can now compile the Haxe project with haxe build.hxml or, for OpenFL projects, lime test windows as you normally would.

Usage

To use hxcpp_JIT, you will need either C++ code or a file containing it. Using a file is recommended for anything bigger than a few lines.

Using without a file

import hxcpp_jit.Cpp;

class Main {
	static function main() {
		var cpp = new Cpp(); // Create a new session
		cpp.eval("
			double half(double x) {
				return x / 2;
			}
		"); // Compile the code
		var result:Float = cpp.call("half", [5.0]); // Call it and get the returned value
		cpp.dispose(); // Free the session
	}
}

Using with a file

eval accepts a path to a file. Pass true as the second argument to always treat the first argument as a file.

import hxcpp_jit.Cpp;

class Main {
	static function main() {
		var cpp = new Cpp();
		cpp.eval("script.cpp", true); // Contains the same code as the script above
		var result:Float = cpp.call("half", [5.0]);
		cpp.dispose();
	}
}

If the second argument is left out, eval treats its first argument as a file only when it points to an existing file. Otherwise it is treated as code. Pass false to never read a file.

cpp.eval("int x = 3;");        // code
cpp.eval("script.cpp");        // file, since it exists
cpp.eval("script.cpp", true);  // file, and an exception is thrown if it doesn't exist
cpp.eval("script.cpp", false); // code

Sessions keep their state

Everything defined by an eval stays available to the next ones.

import hxcpp_jit.Cpp;

class Main {
	static function main() {
		var cpp = new Cpp();
		cpp.eval("int counter = 0;");
		cpp.eval("void bump() { counter += 2; }");
		cpp.call("bump");
		cpp.call("bump");
		trace(cpp.get("counter")); // 4
	}
}

Each Cpp instance is its own session. Functions and variables of one instance can't be seen by another.

Calling functions

call finds a function by its name, works out its signature, and remembers it for the next calls. The function has to be declared with eval first.

cpp.eval("int add(int a, int b) { return a + b; }");
trace(cpp.call("add", [1, 2])); // 3

call returns the value directly. It doesn't catch errors, so use try/catch.

try {
	cpp.call("missing");
} catch (e:hxcpp_jit.CppError) {
	trace(e.message);
}

Argument counts and value kinds are checked before execution; mismatches throw CppError. Pass exactly as many arguments as the function takes. Default arguments of the C++ function can't be used. Arguments are converted to the parameter types like in C++. A const char* parameter only points to the string while the call is running, so use std::string if the function keeps it.

For functions you call a lot, or functions that are overloaded, use bind. For overloaded functions, the return type and the argument types have to be given, since the signature can't be worked out.

cpp.eval("
	double area(double w, double h) { return w * h; }
	int area(int side) { return side * side; }
");

var rect = cpp.bind("area", "double", ["double", "double"]);
trace(rect.call([2.0, 3.0])); // 6
rect.dispose(); // Optional early release; session disposal also releases bound functions

Lambdas and functors work too, as long as they don't have an overloaded operator().

Variables

get evaluates any C++ expression, and set assigns to a C++ lvalue.

cpp.eval("
	struct Point { double x, y; };
	Point point = {1.0, 2.0};
	int arr[4] = {1, 2, 3, 4};
");

trace(cpp.get("point.x + point.y")); // 3
cpp.set("point.x", 1.5);
cpp.set("arr[2]", 7);
trace(cpp.get("arr[2]")); // 7

set can't create variables. A variable has to be declared with eval first, with any value (0, nullptr, or none at all). Setting a variable that doesn't exist throws a CppError.

cpp.set("score", 10); // Throws, `score` doesn't exist
cpp.eval("int score = 0;");
cpp.set("score", 10); // Works

The value is converted to the variable's type like a C++ assignment would, so setting an int to 3.7 stores 3. To make a variable read-only, declare it const.

Strings should go into std::string variables. A const char* variable would point to memory that is freed as soon as set returns.

Value mapping

Values are converted between Haxe and C++ like this:

Haxe	C++
`Int`	integral types, enums
`Bool`	`bool`
`Float`	`float`, `double`
`String`	`const char`, `char`, `std::string`
`CppPointer`	pointers
`null`	`void`, null pointers

bool results come back as Bool. A Bool can also be passed to integral parameters (true is 1). Integers that don't fit in an Int come back as Float. Pointers are stored as numbers, so they are exact for addresses below 2^53.

Structs, classes and containers can't be passed directly. Wrap them in a function or expression that returns one of the types above, like point.x in the example above. Trying to return an unsupported type throws a CppError.

Pointers

Pointers come back as CppPointer instances, which can be passed back to C++.

cpp.eval("int value = 5; int* ptr = &value;");
var p = cpp.get("ptr");
trace(p.isNull()); // false
cpp.set("ptr", null); // Sets it to a null pointer
trace(cpp.get("ptr").isNull()); // true

address returns the address of a symbol by its IR name. Only extern "C" variables and functions have a plain name; other C++ symbols are mangled by the compiler (on Windows, int x; is ?x@@3HA). To get the address of any variable, use get("&x") instead.

cpp.eval("extern \"C\" int shared = 1;");
var addr = cpp.address("shared");
var same = cpp.get("&shared"); // Works for any variable

CppPointer

CppPointer is a native pointer stored as a numeric address. It is returned by get, call and address for pointer values, and it can be passed back to C++ through set and call.

Member	Description
`new CppPointer(address:Float)`	Creates a pointer from a numeric address.
`address:Float`	The address the pointer holds (read-only). It is exact for addresses below 2^53.
`isNull():Bool`	`true` if the address is `0`.
`toString():String`	A readable form, like `JitPtr(0x0000000000401000)`.

import hxcpp_jit.Cpp;
import hxcpp_jit.CppPointer;

class Main {
	static function main() {
		var cpp = new Cpp();
		cpp.eval("int value = 5; int* ptr = &value; int read(int* p) { return *p; }");

		var p:CppPointer = cpp.get("ptr");
		trace(p);            // JitPtr(0x...)
		trace(p.address);    // The address as a Float
		trace(cpp.call("read", [p])); // 5, pointers can be passed back to C++

		var none = new CppPointer(0);
		trace(none.isNull()); // true
		cpp.set("ptr", none); // Same as cpp.set("ptr", null)
	}
}

A CppPointer is only a number. It does not keep the memory it points to alive, and the library does not check that the address is valid, so using a pointer after the variable it points to is gone is undefined behavior, as in C++.

std::string

std::string arguments and results are enabled by default. This needs the C++ standard library headers to be on the machine.

import hxcpp_jit.Cpp;

class Main {
	static function main() {
		var cpp = new Cpp();
		cpp.eval("
			#include <string>
			std::string greet(std::string name) {
				return \"Hello, \" + name;
			}
		");
		trace(cpp.call("greet", ["Haxe"])); // Hello, Haxe
	}
}

If the headers aren't available, creating the session throws a CppError. To skip std::string support, pass false as the second constructor argument. It can be turned on later with enableStdString, which does nothing if it is already on. stdStringEnabled tells you the current state.

var cpp = new Cpp(null, false); // No std::string yet
trace(cpp.stdStringEnabled); // false
cpp.enableStdString(); // Throws a CppError if the headers are missing
trace(cpp.stdStringEnabled); // true

Without std::string support, use const char* in your C++ code.

hxcpp_JIT_setup already installs needed headers.

Supported C++

hxcpp_JIT runs real Clang, so most of C++ works, including:

Templates, namespaces, enums, constexpr, lambdas, functors and recursion.
Classes, inheritance, virtual functions, multiple inheritance, RTTI (dynamic_cast, typeid).
The standard library (<vector>, <map>, <memory>, <functional>, <cmath>, <cstdio> and so on).
Exceptions thrown and caught inside C++ code, including standard exception types, rethrowing, nested exceptions and std::exception_ptr.
thread_local variables and static initializers.

An exception that escapes C++ code back into Haxe is not translated into a CppError, so catch it in C++ (see Errors).

Compiler flags

The first argument of the constructor takes extra flags for Clang. The default standard is -std=c++20.

var cpp = new Cpp(["-std=c++17", "-O2", "-I/my/include"]);

LLVM version

Cpp.LLVM_VERSION is the LLVM version that the library was built with.

trace(Cpp.LLVM_VERSION); // 23.1.4

Errors

Compilation errors, argument-count/type mismatches, and use of disposed Haxe sessions/functions throw a CppError. When C++ code fails to compile, its message contains Clang's diagnostics. Exceptions escaping C++ execution and native faults are not translated into CppError.

import hxcpp_jit.Cpp;
import hxcpp_jit.CppError;

class Main {
	static function main() {
		var cpp = new Cpp();
		try {
			cpp.eval("int broken = nope;");
		} catch (e:CppError) {
			trace(e.message); // Clang's error about the undeclared identifier 'nope'
		}
		cpp.dispose();
	}
}

The session stays usable after a failed eval. Using a session or function after it was disposed throws a CppError too, and disposing twice is safe.

SafeCpp

SafeCpp is Cpp with every call wrapped in a try/catch. Instead of throwing, a failed call returns null (or does nothing for Void functions) and stores the error in lastError. Use it when you would rather check for errors than catch them, for example in scripting or in game code where a bad script shouldn't crash the program.

import hxcpp_jit.SafeCpp;

class Main {
	static function main() {
		var cpp = new SafeCpp();
		cpp.eval("int i = zero;"); // Doesn't throw
		if (cpp.lastError != null)
			trace(cpp.lastError.message); // Clang's error about the undeclared identifier 'zero'
		cpp.dispose();
	}
}

It has the same methods as Cpp: eval, enableStdString, get, set, bind, call, address and dispose, and the same constructor arguments.

onError

Set onError to be called every time an error is caught. It receives the error, the underlying Cpp session (null if the session could not be created), and the name of the method that failed: new, eval, enableStdString, get, set, bind, call, address or dispose. Errors from a function returned by bind are reported as SafeCppFunction.call and SafeCppFunction.dispose.

The last argument is an array with the arguments the method was called with, in the order of its signature. eval("int i = zero;") gives ["int i = zero;", null], set("x", 1, true) gives ["x", 1, true], and call("f", [1, 2]) gives ["f", [1, 2]]. Methods without arguments, like dispose, give an empty array.

var cpp = new SafeCpp();
cpp.onError = (error, session, method, args) -> trace(method + "(" + args + "): " + error.message);
cpp.eval("int i = zero;"); // Prints "eval(int i = zero;,null): " followed by Clang's error

Creating variables

SafeCpp.set takes an optional third argument, autoDeclare. When it is true and the variable doesn't exist yet, set creates it first. The C++ type is picked from the first value.

var cpp = new SafeCpp();
cpp.set("x", 64, true); // Same as cpp.eval("int x{};") followed by cpp.set("x", 64)
trace(cpp.get("x")); // 64

Haxe value	C++ type
`Bool`	`bool`
`Int`	`int`
`Float`	`double`
`String`	`std::string` (needs `stdStringEnabled`)
`CppPointer` or `null`	`void*`

Only plain names are created. point.x or arr[2] still need the variable declared with eval. Haxe can't tell 64 from 64.0 at runtime, so both create an int. Declare the variable with eval for any other type. Later sets convert to the variable's type like a C++ assignment.

autoDeclare is false by default.

Bound functions

bind returns a SafeCppFunction, whose call and dispose report errors to the owning SafeCpp in the same way.

cpp.eval("int add(int a, int b) { return a + b; }");
var add = cpp.bind("add", "int", ["int", "int"]);
trace(add.call([1, 2])); // 3
add.call([1]);           // Wrong argument count, returns null
trace(add.lastError.message);
add.dispose();

Things to know

lastError is not cleared by a successful call, so check the return value, or set it from onError, rather than only testing lastError != null.
A null result can also be a legitimate value (a void function or a null pointer), so use lastError or onError to tell the difference.
cpp holds the underlying Cpp session. It is null if creation failed or after dispose.
SafeCpp is a little slower than Cpp because of the try/catch.

License

hxcpp_JIT is licensed under the Apache License 2.0. See NOTICE for attribution.

The precompiled hxcpp_JIT.dll contains parts of LLVM and Clang (Apache License v2.0 with LLVM Exceptions) and is compressed with UPX. See THIRD_PARTY_NOTICES.md for details. The Microsoft components installed by the setup are licensed by Microsoft under their own terms.

Name		Name	Last commit message	Last commit date
build		build
native		native
src		src
.gitignore		.gitignore
CHANGELOG.md		CHANGELOG.md
CMakeLists.txt		CMakeLists.txt
LICENSE		LICENSE
NOTICE		NOTICE
README.md		README.md
THIRD_PARTY_NOTICES.md		THIRD_PARTY_NOTICES.md
haxelib.json		haxelib.json

Navigation Menu

Repository navigation

About

Repository files navigation

hxcpp_JIT

Installation

Haxe Projects

OpenFL Projects

Requirements

Automatic setup

Building the DLL

Step 1

Step 2

Step 3

Step 4

Usage

Using without a file

Using with a file

Sessions keep their state

Calling functions

Variables

Value mapping

Pointers

CppPointer

std::string

Supported C++

Compiler flags

LLVM version

Errors

SafeCpp

onError

Creating variables

Bound functions

Things to know

License

About

Releases

Packages

Contributors

Languages

Latest commit

History

Folders and files

Repository files navigation

hxcpp_JIT

Installation

Haxe Projects

OpenFL Projects

Requirements

Automatic setup

Building the DLL

Step 1

Step 2

Step 3

Step 4

Usage

Using without a file

Using with a file

Sessions keep their state

Calling functions

Variables

Value mapping

Pointers

CppPointer

std::string

Supported C++

Compiler flags

LLVM version

Errors

SafeCpp

onError

Creating variables

Bound functions

Things to know

License

About

Resources

Stars

Watchers

Forks

Releases

Packages

Contributors

Languages
